	US 12,191,899 B2
	High order digital post-distortion procedures
Elad Meir, Ramat Gan (IL); Gideon Shlomo Kutz, Ramat Hasharon (IL); and Yaron Laufer, Brookline, MA (US)
Assigned to QUALCOMM Incorporated, San Diego, CA (US)
Filed by QUALCOMM Incorporated, San Diego, CA (US)
Filed on Nov. 15, 2021, as Appl. No. 17/526,821.
Prior Publication US 2023/0155617 A1, May 18, 2023
Int. Cl. H04B 1/10 (2006.01); H04L 5/00 (2006.01); H04L 25/02 (2006.01); H04L 25/03 (2006.01)

CPC H04B 1/1027 (2013.01) [H04L 5/0048 (2013.01); H04L 25/0224 (2013.01); H04L 25/03019 (2013.01)]

31 Claims

1. A method for wireless communications at a user equipment (UE), comprising:

receiving, from a base station, a first set of parameters corresponding to a power amplifier model associated with downlink signaling and a second set of parameters corresponding to a non-linear equalizer function;

receiving, from the base station, signaling comprising information associating a set of indices with respective parameters corresponding to the power amplifier model, respective parameters corresponding to the non-linear equalizer function, or both;

performing a digital post-distortion procedure on a downlink signal based at least in part on the first set of parameters corresponding to the power amplifier model and the second set of parameters corresponding to the non-linear equalizer function;

removing a distortion element associated with the downlink signal based at least in part on the digital post-distortion procedure; and

decoding the downlink signal subsequent to removing the distortion element associated with the downlink signal.
