US 12,191,477 B2
Sulfur-carbon composite, preparation method thereof, positive electrode for lithium secondary battery and lithium secondary battery comprising same
Minsu Kim, Daejeon (KR); and Eunkyung Cho, Daejeon (KR)
Assigned to LG ENERGY SOLUTION, LTD., Seoul (KR)
Appl. No. 17/043,877
Filed by LG ENERGY SOLUTION, LTD., Seoul (KR)
PCT Filed Sep. 6, 2019, PCT No. PCT/KR2019/011540
§ 371(c)(1), (2) Date Sep. 30, 2020,
PCT Pub. No. WO2020/060084, PCT Pub. Date Mar. 26, 2020.
Claims priority of application No. 10-2018-0112639 (KR), filed on Sep. 20, 2018; and application No. 10-2019-0109637 (KR), filed on Sep. 4, 2019.
Prior Publication US 2021/0036306 A1, Feb. 4, 2021
This patent is subject to a terminal disclaimer.
Int. Cl. H01M 4/133 (2010.01); H01M 4/02 (2006.01); H01M 4/1393 (2010.01); H01M 4/58 (2010.01); H01M 10/0525 (2010.01)
CPC H01M 4/133 (2013.01) [H01M 4/1393 (2013.01); H01M 4/5815 (2013.01); H01M 10/0525 (2013.01); H01M 2004/028 (2013.01)] 7 Claims
OG exemplary drawing

1. A sulfur-carbon composite comprising:
a porous carbon material, wherein the porous carbon material comprises carbon nanotubes, and wherein the porous carbon material is not graphitized; and
sulfur, wherein the sulfur is present in at least a part of an inside of the porous carbon material and on a surface of the porous carbon material, wherein the sulfur-carbon composite has a specific surface area of 7 m2/g to 20 m2/g and a pore volume of 0.1 cm3/g to 0.3 cm3/g, and
wherein the porous carbon material is a porous carbon material surface-modified with a hydrophilic functional group, where the functional groups have been removed by heat-treating the porous carbon material.
