| CPC G03G 21/168 (2013.01) [G03G 15/1615 (2013.01); G03G 2221/1642 (2013.01)] | 6 Claims |
|
1. An image forming apparatus comprising:
an intermediate transfer unit including an intermediate transferor to bear an image;
a secondary transfer unit including a secondary transfer member and a driving motor that drives the secondary transfer member, the secondary transfer member configured to transfer the image borne by the intermediate transferor to a medium; and
a positioner configured to position the secondary transfer unit with respect to the intermediate transfer unit,
the positioner including:
a first member disposed in the intermediate transfer unit; and
a second member attachable to and detachable from the secondary transfer unit, wherein
the driving motor is integrated with the second member, and
in a state where the second member is detached from the secondary transfer unit, the driving motor is detached from the secondary transfer unit together with the second member.
|
