| CPC E21B 37/02 (2013.01) | 22 Claims |
|
1. A wellbore cleaning tool for cleaning an inner surface of a downhole tubular, comprising:
a housing;
a tool mandrel comprising a generally cylindrical shape, an outer surface, an inner fluid passage, one or more fluid ports, and a mandrel clutch;
a wedge disposed between the tool mandrel and the housing;
a scraper actuator located on the tool mandrel and configured to generate an activation force, wherein the scraper actuator is fluidically coupled to the one or more fluid ports;
a blade assembly located on the tool mandrel proximate the mandrel clutch and comprising one or more scraper blades located in corresponding windows in the housing; and
a control device located on the tool mandrel between the scraper actuator and the blade assembly, and comprising at least one lug located within a control pattern,
wherein an outer surface of each of the one or more scraper blades is configured to contact the inner surface of the downhole tubular.
|
