| CPC A63B 53/0475 (2013.01) [A63B 53/0408 (2020.08); A63B 53/0433 (2020.08); A63B 2053/0491 (2013.01)] | 20 Claims |
|
1. A golf club head comprising:
a body comprising a strike face, a mass pad, a sole, a top rail, a rear wall, and a hosel;
the body enclosing a hollow interior cavity;
wherein the mass pad is located within the hollow interior cavity proximate the sole and the rear wall;
the mass pad comprises a toe mass, a heel mass, and a mass pad central portion between the toe mass and the heel mass;
a weight bar formed separately from the body and coupled thereto;
wherein the weight bar is fully enclosed within the interior cavity;
wherein the weight bar discontinuously engages the mass pad, such that the weight bar is attached to the mass pad at a plurality of discrete attachment locations;
wherein the mass pad is the only portion of the body in contact with the weight bar; and
wherein the plurality of discrete attachment locations comprises a first attachment location on a forward surface of the mass pad central portion and a second attachment location on the toe mass.
|
